| project | Parameter selection | |
| input | Input voltage | 3、3.3、6、6.6、10KV(*) |
| Allowable voltage fluctuation range | Operating at full load, voltage fluctuation ±10% | |
| Frequency range | 50Hz±10% | |
| Input current harmonics | ≤3%, in line with IEEE519-1992 and GB/T14549-93 standards | |
| output | Output voltage range | 3、3.3、6、6.6、10KV(*) |
| Maximum output capacity | 30000KVA | |
| Machine efficiency power factor | Forced air cooling ≥0.965, water cooling frequency conversion ≥0.98 | |
| Output frequency range | 0-50Hz(*) | |
Double waterway parallel design
Reasonable waterway direction
High voltage power devices are used
Water connector on line plug
